| 2021 Skoda Enyaq |
Fuses and Relays
What you should be mindful of
NOTICE
Fire hazard and risk of damage to the electrical system.
▶ Do not repair fuses or replace them with stronger fuses.
▶ Replace the defective fuse with a new fuse with the same amperage.
▶ We recommend using replacement fuses from the ŠKODA
Genuine Accessories range. These guarantee reliable and safe
protection of the vehicle’s electric system.
▶ If a newly inserted fuse blows again, seek the help of a specialist garage.
One fuse may belong to several consumers. One consumer may have several fuses.
High-voltage system fuse (fuse for rescue workers)
The high-voltage system fuse is provided with a yellow sticker so that the emergency services can switch off the high-voltage in the vehicle as quickly as possible.
WARNING
Danger to life or risk of an electric shock and serious burns!
▶ Do not change the high-voltage system fuse yourself!
▶ Seek the help of a specialist garage.
Danger to life or risk of an electric shock and serious burns!
▶ Do not change the high-voltage system fuse yourself!
▶ Seek the help of a specialist garage.
Functionality
Fuses protect the vehicle systems from damage caused by excessive
current. The fuse blows when the current is exceeded.
 |
| Blown Fuse |
Conditions for replacing a fuse
✓ Ignition off
✓ Driver door opened
✓ All consumers switched off
Fuses in the dash panel
Access to fuses – left hand drive
 |
| Dashboard Fuse Pane - Left Hand Drive |
› Open the storage compartment on the driver's side.
› Press the locking lugs and open the tray.
› Change the fuse.
› Close the storage compartment.
› Press the locking lugs and open the tray.
› Change the fuse.
› Close the storage compartment.
Access to fuses – right-hand drive
 |
| Access to fuses – right-hand drive |
› Open the storage compartment on the passenger's side.
› Loosen the brake rod of the storage compartment.
› Loosen the brake rod of the storage compartment.
› Press the locking lugs, the storage compartment folds down.
› Open the fuse box cover.
› Change the fuse.
› Close the fuse box cover.
› Insert and lock the brake rod.
› Close the storage compartment.
› Change the fuse.
› Close the fuse box cover.
› Insert and lock the brake rod.
› Close the storage compartment.
 |
| Dashboard Fuse Panel Diagram |
Fuse number ... Consumer
1 230 volt socket
2 Airbags
3 Tow hitch
4 Front camera for assistance systems
5 Vehicle exterior lighting
6 Interior lighting
7 Heating of the front seats
8 Sliding/tilting roof
9 Window lifter (left vehicle side), central locking (left front door), left exterior mirror (heater, folding function, mirror surface adjustment)
10 Not used
11 Tow hitch
12 Not used
13 Central locking (rear doors and boot lid flap), windscreen washer system, headlight cleaning system
14 Music amplifier
15 Not used
16 Not used
17 Rear radar sensors
18 Steering column lock, KESSY (keyless locking system), contactless operation of the electric luggage compartment lid
19 Instrument cluster, emergency call, online services
20 Phonebox, USB-connections at the front
21 Rear view camera, Top View
22 Engine control system
23 Communication system
24 Not used
25 Driver belt tensioners
26 Window lifter – right vehicle side, central locking (right front door), right exterior mirror (heater, folding function, mirror surface adjustment)
27 Passenger belt tensioners
28 High-voltage battery control system - safe shutdown of the high-voltage system
The fuse can only be changed by a specialist company!
29 Tow hitch
30 Infotainment
31 Tow hitch
32 Vehicle exterior lighting
33 Not used
34 Air conditioning
35 Seat heating - rear
36 Fan for heating/air conditioning
1 230 volt socket
2 Airbags
3 Tow hitch
4 Front camera for assistance systems
5 Vehicle exterior lighting
6 Interior lighting
7 Heating of the front seats
8 Sliding/tilting roof
9 Window lifter (left vehicle side), central locking (left front door), left exterior mirror (heater, folding function, mirror surface adjustment)
10 Not used
11 Tow hitch
12 Not used
13 Central locking (rear doors and boot lid flap), windscreen washer system, headlight cleaning system
14 Music amplifier
15 Not used
16 Not used
17 Rear radar sensors
18 Steering column lock, KESSY (keyless locking system), contactless operation of the electric luggage compartment lid
19 Instrument cluster, emergency call, online services
20 Phonebox, USB-connections at the front
21 Rear view camera, Top View
22 Engine control system
23 Communication system
24 Not used
25 Driver belt tensioners
26 Window lifter – right vehicle side, central locking (right front door), right exterior mirror (heater, folding function, mirror surface adjustment)
27 Passenger belt tensioners
28 High-voltage battery control system - safe shutdown of the high-voltage system
The fuse can only be changed by a specialist company!
29 Tow hitch
30 Infotainment
31 Tow hitch
32 Vehicle exterior lighting
33 Not used
34 Air conditioning
35 Seat heating - rear
36 Fan for heating/air conditioning
37 Electric boot lid
38 Seat ventilation
39 Heated steering wheel
40 Alarm horn
41 Databus
42 Transmission operation, transmission mode display
43 Front air conditioning, rear air conditioning, rear window heating
44 Front interior lighting, parking brake, rain light sensor, operation of the light function, alarm system, diagnostic connection, button bar in the control panel
38 Seat ventilation
39 Heated steering wheel
40 Alarm horn
41 Databus
42 Transmission operation, transmission mode display
43 Front air conditioning, rear air conditioning, rear window heating
44 Front interior lighting, parking brake, rain light sensor, operation of the light function, alarm system, diagnostic connection, button bar in the control panel
45 Control lever under the steering wheel
46 Infotainment screen, Head-up display
47 Adaptive Chassis Control (DCC)
48 Rear USB
49 Not used
50 Not used
51 Not used
52 12 volt socket in the luggage compartment
53 Not used
54 Not used
55 Not used
56 Not used
57 Not used
58 Parking aid (Park Assist)
59 Air conditioning + heating, interior mirror with automatic dimming, USB at the rear
60 Diagnostic connection
61 Drive system
62 Not used
63 Not used
64 Not used
65 Not used
66 Rear window wiper
67 Heated rear window
46 Infotainment screen, Head-up display
47 Adaptive Chassis Control (DCC)
48 Rear USB
49 Not used
50 Not used
51 Not used
52 12 volt socket in the luggage compartment
53 Not used
54 Not used
55 Not used
56 Not used
57 Not used
58 Parking aid (Park Assist)
59 Air conditioning + heating, interior mirror with automatic dimming, USB at the rear
60 Diagnostic connection
61 Drive system
62 Not used
63 Not used
64 Not used
65 Not used
66 Rear window wiper
67 Heated rear window
Fuses in the space under the front flap
Access to the fuses
 |
| Fuses in the space under the front flap |
› Simultaneously press the locking buttons on the fuse box cover and remove the cover.
› Change the fuse.
› Fit the cover and click into place.
› Change the fuse.
› Fit the cover and click into place.
NOTICE
Danger of water entering the fuse box.
▶ Fit the cover correctly and click into place securely.
 |
| Space under the front flap Fuse Panel Diagram |
Fuse number ... Consumer
1 Not used
2 Assistance system ESC, BDM control system, coil of the main relay
3 Charger for the high-voltage battery, electric drive
4 Left headlight
5 Right headlight
6 Radar sensor in the front
7 Not used
8 Not used
9 Horn
10 Windscreen wiper
11 Air conditioning
12 Engine sound generator
13 Assistance system ESC ( Electronic Stability Control)
14 Not used
15 Assistance system ESC
16 Radiator fan
17 Heated windscreen
18 Not used
19 Not used
20 Not used
21 Not used
22 Not used
23 Engine control system
24 Radiator fan
25 Coolant pump, electric heating
26 Coolant pump, radiator shutter
27 Not used
28 Not used
29 Not used
30 Not used
31 Not used
32 Brake servo
