2012 - 2017 Mitsubishi Lancer Fuse Box Diagram

2017 Mitsubishi Lancer

Fuse replacement

1. Before replacing a fuse, always turn off the electrical item connected to the fuse and turn the ignition switch to the “LOCK” position.
2. There is a fuse puller (A) in the engine compartment fuse block.



Fuse Puller Location

3. Clamp it on the fuse you wish to remove, and pull the fuse straight out from the fuse block.



4. Use the fuse location diagrams and the matching tables, to check the fuse that is related to the problem. If the fuse is not blown, something else must be causing the problem. Contact an authorized Mitsubishi Motors dealer or a repair facility of your choice to have the problem
checked.

B- Fuse is OK ,  C- Blown fuse

5. Insert a new fuse of the same capacity securely into the appropriate slot.

CAUTION

Never use a fuse with a capacity greater than the one listed or any substitute, such as wire,
foil etc. This would cause the circuit wiring to heat up and could cause a fire.

CAUTION
If the replacement fuse blows again after a short time, have the electrical system checked by an authorized Mitsubishi Motors dealer or a repair facility of your choice to find and correct the cause.

Identification of fuse



Capacity .. Color
7.5 A Brown
10 A Red
15 A Blue
20 A Yellow
25 A Natural (White)
30 A Green (fuse type)/Pink (fusible link type)
40 A Green

Fuse block location

To prevent damage to the electrical system from short-circuiting or overloading, each  individual circuit is equipped with a fuse. The fuse blocks are located in the passenger compartment and in the engine compartment.

Passenger compartment Fuse Panel

Passenger compartment : A- Main fuse block , B- Sub fuse block

The fuse blocks in the passenger compartment are located behind the fuse lid on the driver’s side as shown.

1. Open the fuse lid and pull to remove it.

Open the fuse lid and pull to remove it



2. For vehicles with the bottom cover, use the puller to loosen the 2 clips (A) and push down the bottom cover. The puller is in the fuse block in the engine compartment.

Vehicles with the bottom cover

WARNING

When changing fuses, do not damage the driver’s knee airbag harness or accidentally strike the airbag area with hard objects. Improper work methods could result in an accidental  driver’s knee airbag deployment or could make the driver’s knee airbag inoperable. Either of
these situations could result in serious injury or death.

NOTE

When finished, be sure to return the puller to the fuse block in the engine compartment

3. To put back the fuse lid, line up the fuse lid hook (B) with the clamp (C) on the instrument panel and push the lid back in.

Put back the fuse lid



Engine compartment Fuse Box

In the engine compartment, the fuse block is located as shown in the illustration.



Engine Compartment Fuse Box



1. Push the lock lever.
2. Remove the fuse block cover.


Fuse load capacities



This fuse list shows the names of the electrical systems and their fuse capacities.
There are spare fuses in the cover of the fuse block in the engine compartment. Always
replace a blown fuse with one of the same capacity as the original.

Passenger compartment fuse location table

Main Fuse Block, Sub Fuse Block

Passenger compartment fuse Panel Diagram

No. ..  Electrical system ..  Capacity
1 Heater 30 A*
2 Stop lights (Brake lights) 15 A
3 Rear fog light 10 A
4 Windshield wiper 30 A
5 Optional 10 A
6 Door locks 20 A
7 Radio 15 A
8 Control unit relay 7.5 A
9 Interior lights (Dome lights) 15 A
10 Hazard warning flasher 15 A
11 Rear window wiper 15 A
12 Gauges 7.5 A
13 Cigarette lighter / Accessory socket 15 A
14 Ignition switch 10 A
15 Sunroof 20 A
16 Outside rearview mirrors 10 A
17 All-wheel drive system 10 A
18 Back-up lights 7.5 A
19 Accessory socket 15 A
20 Power window control 30 A*
21 Defogger 30 A*
22 Heated outside rearview mirrors 7.5 A
23 115V Power outlet 15 A
24 Power seats 25 (20)A
25 Heated seats 30 A

*- Fusible link



- Some fuses may not be installed on your vehicle, depending on the vehicle model or specifications.

- The table above shows the main equipment corresponding to each fuse.

Engine compartment fuse location table

Engine Compartment Fuse Panel Diagram

*- Front of the vehicle

No. .. Electrical system .. Capacity
1 Front fog lights 15 A
2 Engine 7.5 A

3 Automatic transaxle 20 A
4 Horn 10 A
5 Alternator 7.5 A
6 Headlight washer 20 A
7 Air conditioning 10 A
8 / ETV/Oil cooler fan (Twin Clutch SST) 15 A
9 Security horn 20 A
10 Wiper deicer 15 A
11 — — —
12 Power gate 30 A
13 Daytime running lights 10 A
14 Headlight (high beam) (left) 10 A
15 Headlight (high beam) (right) 10 A
16 Headlight (low/high beam) (left)  Discharge 20 A
17 Headlight (low/high beam) (right) Discharge 20 A
18 Headlight (low beam) (left) Halogen 10 A
19 Headlight (low beam) (right) Halogen 10 A

20 ENG/ POWER 10 A
21 Ignition coil 10 A
22 ENG/ POWER 20 A  , Fuel line heater 25 A
23 Fuel pump 15 A
24 Starter 30 A*
25 Valve lift control 40 A*
26 Anti-lock braking system (ABS) 40 A*
27 Anti-lock braking system (ABS) 30 A*
28 Air conditioning condenser fan motor 30 A*
29 Radiator fan motor 40 A*
30 IOD IOD 30 A
31 Audio amplifier 30 A
32 Diesel 30 A
33 — Spare (Extra) fuse 10 A
34 — Spare fuse 15 A
35 — Spare fuse 20 A

*- Fusible link

- Some fuses may not be installed on your vehicle, depending on the vehicle model or specifications.

- The table above shows the main equipment corresponding to each fuse.

There are no 7.5 A, 25 A or 30 A spare fuses.
If a fuse of one of these capacities blows, replace it temporarily by borrowing one of the fuses indicated below.
7.5 A: 10 A spare fuse
25 A: 20 A spare fuse
30 A: 30 A audio amplifier fuse

Replace the borrowed fuse with a fuse that has the correct capacity as soon as possible.
