2017 - 2020 Chevrolet Trax Fuse Box Diagram

2017 Chevrolet Trax



Fuses and Circuit Breakers

The wiring circuits in the vehicle are protected from short circuits by a combination of fuses and circuit breakers. This greatly reduces the chance of damage caused by electrical problems.
To check a fuse, look at the silver-colored band inside the fuse.
If the band is broken or melted, replace the fuse. Be sure to replace a bad fuse with a new one of the identical size and rating.
Fuses of the same amperage can be temporarily borrowed from another fuse location, if a fuse goes out. Replace the fuse as soon as possible.



Engine Compartment Fuse Block

Engine Compartment Fuse Block Location



To remove the fuse block cover, squeeze the clip and lift it up.


Caution
Spilling liquid on any electrical component on the vehicle may damage it. Always keep the
covers on any electrical component.

Engine Compartment Fuse Panel Diagram

The vehicle may not be equipped with all of the fuses, relays, and features shown.

Mini Fuses  ... Usage
1 Sunroof
2 Exterior rearview mirror switch/Driver side power window/ Rain sensor/ Universal garage  door opener
3 Canister vent solenoid
4 –
5 Electronic brake control module valve
6 Intelligent battery sensor
7 Electric steering column lock
8 Transmission control module/FICM
9 Automatic occupancy sensing module
10 Headlamp leveling switch/Headlamp leveling motor/Rear vision camera/ Interior rearview
mirror
11 Rear wiper
12 Rear window defogger
13 Power lumbar switch
14 Exterior rearview mirror heater
15 Fuel system control module battery
16 Heated seat module/ Memory module
17 TIM DC DC converter/Fuel system control module RC/ Compass module
18 Engine control module RC/ Transmission control module RC/ FICM RC
19 Fuel pump

20 –
21 Fan relay (auxiliary BEC)
22 –
23 Ignition coil/ Injector coil
24 Washer pump
25 Automatic headlamp leveling
26 EMS Var 1
27 –
28 –
29 Engine control module powertrain/ Ignition 1/Ignition 2
30 EMS Var 2
31 Left high-beam headlamp
32 Right high-beam headlamp
33 Engine control module battery
34 Horn
35 A/C (Air Conditioner) clutch
36 Front fog lamps

J-Case Fuses .. Usage
1 Electronic brake control module pump
2 Front wiper
3 Linear power module blower
4 IEC RC
5 –
6 –
7 –
8 Cooling fan low – mid
9 Cooling fan – high
10 EVP
11 Starter solenoid

U-Micro Relays ... Usage
2 Fuel pump
4 –



HC-Micro Relays .. Usage
7 Starter

Mini Relays ... Usage
1 Run/Crank
3 Cooling fan – mid
4 –
5 Powertrain relay
8 Cooling fan – low

HC-Mini Relays .. Usage
6 Cooling fan – high



Auxiliary Fuse Block

Auxiliary Fuse Block

To remove the fuse block cover, squeeze the clips and lift it up.

Caution
Spilling liquid on any electrical component on the vehicle may damage it. Always keep the
covers on any electrical component.

Auxiliary Fuse Panel Diagram

The vehicle may not be equipped with all of the relays and features shown.

Relays .. Usage
01 Electric vacuum pump
02 Cooling fan control 1
03 Cooling fan control 2
04 Trailer (1.4L only)



Instrument Panel Fuse Block

Instrument Panel Fuse Block

The instrument panel fuse block is on the underside of the driver side instrument panel. To access the fuses, remove the storage compartment. To remove the storage compartment, open the compartment and pull it out.



Instrument Fuse Panel Diagram

The vehicle may not be equipped with all of the fuses, relays, and features shown.

Fuses ... Usage
F1 Body control module 1
F2 Body control module 2
F3 Body control module 3
F4 Body control module 4
F5 Body control module 5
F6 Body control module 6
F7 Body control module 7
F8 Body control module 8
F9 Discrete logic ignition switch
F10 Sensing diagnostic module battery
F11 Data link connector
F12 HVAC module/ICS
F13 Liftgate relay
F14 Central gate module
F15 Lane departure warning/GENTEX
F16 –
F17 Electrical steering column lock
F18 Parking assist module/Side blind zone alert
F19 Body control module/Regulated voltage control
F20 Clock spring
F21 A/C/Accessory power outlet/ PRNDM
F22 Auxiliary power outlet/DC front
F23 HVAC/MDL/ICS
F24 –
F25 OnStar module/ Eraglonass

F26 Heated steering wheel (2020 Model - Electric vacuum pump)
F27 Instrument cluster/ Auxiliary heater/ Auxiliary virtual image display F28 Trailer feed 2
F29 Faceplate
F30 DC DC 400W
F31 Instrument cluster module battery
F32 Silver box audio module/Navigation
F33 Trailer feed 1
F34 Passive entry/ Passive start

Midi Fuses .. Usage
M01 Positive temperature coefficient

S/B Fuses .. Usage
S/B01 Passenger power seat 1
S/B02 – (2020 Model - Powertrain cooling – 2)
S/B03 Front power windows
S/B04 Rear power windows
S/B05 Logistic mode relay/ DC DC 400W
S/B06 Driver power seat
S/B07 –
S/B08 Trailer interface module

Circuit Breaker .. Usage
CB1 –

Relays  ... Usage
RLY01 Accessory/Retained accessory power
RLY02 Liftgate
RLY03 –
RLY04 Blower
RLY05 Logistic mode

Rear Compartment Fuse Block



Rear Compartment Fuse Block

The rear compartment fuse block is behind a cover on the driver side of the rear   compartment. To access the fuses, remove the cover.
The vehicle may not be equipped with all of the fuses, relays, and features shown.

2017 Model



2017 Model - Rear Compartment Fuse Panel Diagram



Fuses .. Usage
F1 –
F2 –
F3 Amplifier audio
F4 –
F5 Rear drive control module
F6 Left cornering lamp
F7 Right cornering lamp
F8 –
F9 –
F10 –
F11 –
F12 –
F13 –
F14 –
F15 –
F16 –
F17 –
F18 –

S/B Fuses .. Usage
S/B01 –
S/B02 –
S/B03 –
S/B04 DC/AC inverter module
S/B05 –
S/B06 –
S/B07 DC-DC transformer 400W
S/B08 DC-DC transformer 400W
S/B09 –

Relays .. Usage
RLY01 Right cornering lamp
RLY02 Left cornering lamp

2018 - 2020 Model

2018 - 2020 Model - Rear Compartment Fuse Panel Diagram



Fuses .. Usage
F1 Amplifier audio
F2 Rear drive control module
F3 –
F4 –
F5 –
F6 –
F7 –
F8 –
F9 –
F10 –
F11 –
F12 –
F13 –
F14 –
F15 –
F16 –
F17 –

S/B Fuses .. Usage
S/B01 DC-DC transformer 400W
S/B02 DC-DC transformer 400W
S/B03 DC/AC inverter module
S/B04 –
S/B05 –

Relays .. Usage
RLY01 –
RLY02 –
RLY03 –
RLY04 –
RLY05 –

Circuit Breakers Usage
CB1 –
