| 2017 Vauxhall (Opel) Astra |
Data on the replacement fuse must match the data on the defective fuse.
There are three fuse boxes in the vehicle:
■ In the front left of the engine compartment,
■ In left-hand drive vehicles, in the interior behind the storage compartment, or, in right-hand drive vehicles, behind the glovebox,
■ Behind a cover on the left side of the load compartment.
Before replacing a fuse, turn off the respective switch and the ignition.
A blown fuse can be recognized by its melted wire. Do not replace the fuse until the cause of the fault has been remedied.
Some functions are protected by several fuses.
Fuses may also be inserted without existence of a function.
There are three fuse boxes in the vehicle:
■ In the front left of the engine compartment,
■ In left-hand drive vehicles, in the interior behind the storage compartment, or, in right-hand drive vehicles, behind the glovebox,
■ Behind a cover on the left side of the load compartment.
Before replacing a fuse, turn off the respective switch and the ignition.
A blown fuse can be recognized by its melted wire. Do not replace the fuse until the cause of the fault has been remedied.
Some functions are protected by several fuses.
Fuses may also be inserted without existence of a function.
Fuse extractor
A fuse extractor may be located in the fuse box in the engine compartment.
Place the fuse extractor on the various types of fuse from the top or side, and withdraw fuse.
 |
| Fuse extractor |
Engine compartment fuse box
The fuse box is in the front left of the engine compartment.
Disengage the cover and fold it upwards until it stops. Remove the cover vertically upwards.
 |
| Engine Compartment Fuse Box |
 |
| Engine Compartment Fuse Panel Diagram |
No. Circuit
1 Engine control module2 Lambda sensor
3 Fuel injection, ignition system
4 Fuel injection, ignition system
5 –
6 Mirror heating, anti-theft alarm system
7 Fan control, engine control module, transmission control module
8 Lambda sensor, engine cooling
9 Rear window sensor
10 Vehicle battery sensor
11 Trunk release
12 Adaptive forward lighting, automatic light control
13 ABS
14 Rear window wiper
15 Engine control module
16 Starter
17 Transmission control module
18 Heated rear window
19 Front power windows
20 Rear power windows
21 Rear electrical centre
22 Left high beam (Halogen)
23 Headlamp washer system
24 Right low beam (Xenon)
25 Left low beam (Xenon)
26 Front fog lights
27 Diesel fuel heating
28 Start stop system
29 Electric parking brake
30 ABS
31 Adaptive cruise control
32 Airbag
33 Adaptive forward lighting, automatic light control
34 Exhaust gas recirculation
35 Exterior mirror, rain sensor
36 Climate control
37 Canister vent solenoid
38 Vacuum pump
39 Central control module
40 Windscreen washer, rear window washer system
41 Right high beam (Halogen)
42 Radiator fan
43 Windscreen wiper
44 Windscreen wiper
45 Radiator fan
46 –
47 Horn
48 Radiator fan
49 Fuel pump
50 Headlamp levelling, adaptive
forward lighting
51 Air shutter
52 Auxiliary heater, diesel engine
53 Transmission control module, engine control module
54 Vacuum pump, instrument panel cluster, heating ventilation, air conditioning system
After having changed defective fuses close the fuse box cover and press until it engages.
If the fuse box cover is not closed correctly, malfunction may occur.
Instrument panel fuse box
 |
| Instrument panel fuse box in left-hand drive vehicles |
In Left-hand drive vehicles, the fuse box is behind the storage compartment in the instrument panel.
Open the compartment and push it to the left to unlock. Fold the compartment down and remove it.
 |
| Instrument panel fuse box in Right-hand drive vehicles |
In Right-hand drive vehicles, the fuse box is located behind a cover in the glovebox. Open the glovebox, then open the cover and fold it down.
 |
| Fuse assignments |
No. Circuit
1 Displays2 Exterior lights, body control module
3 Exterior lights, body control module
4 Infotainment system
5 Infotainment system, instrument
6 Power outlet, cigarette lighter
7 Power outlet
8 Left low beam, body control module
9 Right low beam, body control module, airbag module
10 Door locks, body control module
11 Interior fan
12 –
13 –
14 Diagnostic connector
15 Airbag
16 Power outlet
17 Air conditioning system
18 Logistics
19 Body control module
20 Body control module
21 Instrument panel cluster, antitheft alarm system
22 Ignition sensor
23 Body control module
24 Body control module
25 –
26 Power outlet load compartment (if no load compartment fuse box) (Sports tourer only)
Load compartment fuse box
3-door hatchback, 5-door hatchback
The fuse box is on the left side of the load compartment behind a cover. Remove the cover.
Sports tourer
The fuse box is on the left side of the load compartment behind a cover.
 |
| Fold down the blind and remove. |
 |
| Remove the cover. |
Fuse assignments
 |
| Load compartment Fuse Panel Diagram |
When assembling press the blind into the rubber grommets to reach full retention force.
No. Circuit
1 –2 Trailer outlet
3 Parking assist
4 –
5 –
6 –
7 Power seat
8 –
9 –
10 –
11 Trailer module, trailer socket
12 Trailer module
13 Trailer outlet
14 Rear seat, electrical folding
15 –
16 Inside mirror, rear view camera
17 Power outlet
18 –
19 Steering wheel heating
20 Sunroof
21 Heated front seats
22 –
23 –
24 –
25 –
26 – (2017 Model - Deactivated logistic mode)
27 –
28 –
29 –
30 –
31 Amplifier, subwoofer
32 Active damping system, lane departure warning
