2018 - 2022 Mitsubishi Eclipse Cross Fuse Box Diagram

2022 Mitsubishi Eclipse Cross



Fuses and Relays



To prevent damage to the electrical system from short-circuiting or overloading, each  individual circuit is equipped with a fuse. The fuse blocks are located in the passenger  compartment and in the engine compartment.


Passenger compartment



The fuse block in the passenger compartment is located behind the fuse lid in front of the
driver’s seat at the position shown in the illustration.
Pull the fuse lid to remove it.

Passenger compartment Fuse Block Location



Passenger compartment Fuse Panel Diagram


No.  ... Electrical system   ... Capacity
1 Power window control 30 A*
2 Defogger 30 A*
3 Heater 30 A
4 Windshield wipers 30 A
5 Door locks 25 A
6 — — —
7 12 V power outlet 15 A
8 Rear window wiper 15 A
9 Sunroof 20 A
10 Ignition switch 10 A
11 Option 10 A
12 Hazard warning flasher 15 A
13 4-wheel drive system 10 A
14 Stop lights (Brake lights) 15 A
15 Gauges 10 A
16 SRS airbag 7.5 A
17 Radio 15 A
18 Control unit relay 7.5 A
19 Interior lights (Room lights) 15 A
20 Back-up lights 7.5 A
21 Heated outside rearview mirrors 7.5 A
22 Outside rearview mirrors 10 A
23 Cigarette lighter/ 12 V power outlet 15 A



*: Fusible link



 -  Some fuses may not be installed on your vehicle, depending on the vehicle model or specifications.
-  The table above shows the main equipment corresponding to each fuse.

Engine compartment Fuse Box



The fuse block in the engine compartment is located as shown in the illustration. Press the lock lever (1) and remove the fuse block cover (2).

Engine Compartment Fuse Block Location

Engine Compartment Fuse Panel Diagram

Behind the fuse block cover


No.  ... Electrical system   ... Capacity
1 Electric parking brake 30 A*
2 Electric parking brake 30 A*
3 Anti-lock braking system (ABS) 40 A*
4 Anti-lock braking system (ABS) 30 A*
5 — — — (2018 - 2019 Models - Power seat 30 A*
6 Heated seats 30 A
7 Starter 30 A*
8 Alternator 7.5 A
9 Headlight washer 20 A
10 Security horn 20 A
11 Automatic transaxle 20 A
12 Horn 10 A
13 Sunshade 20 A
14 Front fog lights 15 A
15 Daytime running lights 10 A
16 Air conditioner 10 A
17 Engine control unit 7.5 A
18 Audio system amplifier 15 A
19 Radiator fan motor 40 A*
20 Power seat (Driver seat) 30 A
21 Power seat (Passenger seat) 30 A
22 IOD IOD 30 A
23 Air conditioning condenser fan motor 30 A*
24 Battery current sensor 7.5 A
25 / Electric parking brake/Adaptive Cruise Control (ACC) 7.5 A
26 Headlight (high beam) (right) 10 A
27 Headlight (high beam) (left) 10 A
28 Turbo actuator 20 A
29 ENG/POWER 20 A
30 Fuel pump 15 A
31 Ignition coil 10 A
32 Injector 20 A
33 ETV ( Exhaust Throttle Valve) 15 A
#1 — Spare fuse 10 A
#2 — Spare fuse 15 A
#3 — Spare fuse 20 A



*: Fusible link



 -  Some fuses may not be installed on your vehicle, depending on the vehicle model or specifications.
-  The table above shows the main equipment corresponding to each fuse.

The fuse block does not contain spare 7.5 A, 25 A or 30 A fuses. If one of these fuses burns out, substitute with the following fuse.
7.5 A: 10 A spare fuse
25 A: 20 A spare fuse
30 A: 30 A power seat (passenger seat) fuse
When using a substitute fuse, replace with a fuse of the correct capacity as soon as possible.

Fuse load capacities



This fuse list shows the names of the electrical systems and their fuse capacities.
There are spare fuses in the fuse block cover in the engine compartment. Always replace a
blown fuse with one of the same capacity as the original.

Identification of fuse

Capacity .. Color
7.5 A Brown
10 A Red
15 A Blue
20 A Yellow
25 A Natural (white)
30 A Green (fuse type) / Pink (fusible link type)
40 A Green (fusible link type)

Fuse replacement

1. Before replacing a fuse, always turn off the electrical item connected to the fuse and turn  the ignition switch to the “OFF” position or put the operation mode in OFF.
2. There is a fuse remover (A) in the engine compartment fuse block.



Fuse Puller Location

3. Clamp it on the fuse you wish to remove, and pull the fuse straight out from the fuse block.


Fuse Puller

4. Use the fuse location diagrams and the matching tables, to check the fuse that is related to the problem. If the fuse is not blown, something else must be causing the problem. Have the system inspected by your authorized Mitsubishi Motors dealer or a repair facility of your choice.



Blown Fuse

B - Fuse is OK
C - Blown fuse

5. Insert a new fuse of the same capacity securely into the appropriate slot.

CAUTION
-  Never use a fuse with a capacity greater than the one listed or any substitute, such as wire,
foil etc. This would cause the circuit wiring to heat up and could cause a fire.

-  If the replacement fuse blows again after a short time, have the electrical system checked by an authorized Mitsubishi Motors dealer or a repair facility of your choice to find and correct the cause.
