2011 - 2017 Chevrolet Equinox Fuse Panel Diagram

2017 Chevrolet Equinox



Fuses

The wiring circuits in the vehicle are protected from short circuits by fuses. This greatly reduces the chance of damage caused by electrical problems.
Look at the silver-colored band inside the fuse. If the band is broken or melted, replace the fuse. Be sure to replace a bad fuse with a new one of the identical size and rating.
Replace a bad fuse with a new one of the identical size and rating. If there is a problem on the road and a fuse needs to be replaced, the same amperage fuse can be borrowed.

Choose some feature of the vehicle that is not needed to use and replace it as soon as possible.

There are two fuse blocks in the vehicle: one in the engine compartment and one in the  instrument panel.
There is a Fuse Puller located in the engine compartment fuse block.
It can be used to easily remove fuses from the fuse block.

Engine Compartment Fuse Block

Engine Compartment Fuse Block

To remove the fuse block cover, squeeze the clips on the cover and lift it straight up.

Spilling liquid on any electrical component on the vehicle may damage it. Always keep the
covers on any electrical component.



Engine Compartment Fuse Panel Diagram



The vehicle may not be equipped with all of the fuses, relays, and features shown.

Fuses ... Usage
1 Cooling fan 1
2 Cooling fan 2
3 Brake booster
4 Right power windows
5 Memory seat module
6 Left power seat
7 Instrument panel fuse block 1
8 Rear defogger
9 Starter
10 AIR pump motor

11 Instrument panel fuse block 2
12 Sunroof
13 Antilock Brake System (ABS) pump
14 Instrument panel fuse block 3
15 Left power windows
16 Antilock Brake System (ABS) module
17 Transmission control module battery
18 Trailer parking light
19 AIR pump solenoid
20 Engine control module battery
21 Canister vent
22 Left trailer side (if equipped)
23 Liftgate module
24 Power lumbar
25 Right trailer side (if equipped)

26 Rear accessory power outlet
27 Memory mirror module
28 Regulated voltage control battery sensor
29 Front wiper
30 Rear wiper
31 A/C (Air Conditioning Compressor )
32 Rear latch
33 Heated mirrors
34 Horn
35 Right high-beam headlamp
36 Left high-beam headlamp
37 Ignition coil – even
38 Ignition coil – odd
39 Windshield washer
40 Front fog lamps (if equipped)

41 Post catalytic converter O2 sensor
42 Engine control module
43 Pre-catalytic converter O2 sensor
44 Transmission control module
45 Mirror
46 Fuel system control module/Ignition
47 –
48 Rear drive module
49 Lift gate module logic
50 Instrument panel fuse block/Ignition
51 Front heated seat
52 Fuel system control module
53 Engine control module
54 Rear vision camera

55 Electric power steering
56 AIR pump solenoid
57 Brake booster
58 Cooling fan – low
59 High-beam headlamps
60 Cooling fan control
61 Wiper On/Off control
62 A/C (Air Conditioning Compressor)
63 Rear defogger
64 Wiper speed
65 Fog lamps
66 Engine control
67 Starter
68 Run/Crank
69 Cooling fan – high
70 AIR pump motor

77 Right power seat
78 Passenger power lumbar

Instrument Panel Fuse Block



Instrument Panel Fuse Block

The instrument panel fuse block is located on the passenger side panel of the center console. To access the fuses, open the fuse panel door from the passenger side by pulling it out.
To reinstall the door, insert the tabs on the top of the door into the console first, then push the door back into its original location.
The vehicle may not be equipped with all of the fuses, relays, and features shown.


Instrument Fuse Panel Diagram

Fuses .. Usage


1 Steering wheel dimming
2 –
3 –
4 Body control module 1
5 Infotainment
6 Body control module 7
7 Noise control module
8 Body control module 4
9 Radio
10 – (2011 Model - Special Equipment Order Battery)

11 Rear parking assist module
12 (Heater, Ventilation and Air Conditioning Battery) HVAC/Battery
13 Front auxiliary power
14 HVAC/Ignition
15 Display

16 Body control module 5
17 Rear auxiliary power
18 Instrument panel/ Ignition

19 Universal garage door opener
20 Body control module 6
21 –
22 Sensing/Diagnostic module/Ignition
23 Front vision camera
24 –
25 Transmission gear shift position indicator
26 –
27 –
28 –
29 Front blower motor
30 Body control module 3

31 Amplifier
32 Discrete logic ignition switch
33 Communications integration module
34 Body control module 2
35 Sensing/Diagnostic module battery
36 Data link connector
37 Instrument panel battery
38 Passenger sensing system module
39 –
40 Body control module 8
41 Logistic relay (if equipped)
42 Retained accessory power relay
