2012 - 2014 Skoda Rapid - Fuse Box Diagram

2013 Skoda Rapid
2013 Skoda Rapid

More Fuses Skoda Rapid Models : 2015  ,  2016 - 2018  ,   2019


Fuses and Relays


Individual electrical circuits are protected by fuses.
Switch off the ignition and the corresponding power consuming device before replacing a fuse.
Find out which fuse belongs to the component that is not operating.

Note
■ We recommend always carrying replacement fuses in the vehicle. A box of replacement fuses can be purchased from ŠKODA Original Accessories.
■ There can be several power consuming devices for one fuse.
■ There can be several consumer devices for one fuse, depending on the vehicle's equipment.
■ Multiple fuses may exist for a single power consuming device.
■ Multiple power consuming devices can share a single fuse.

Fuses in the Dash Panel

The fuses are located on the bottom left of the dash panel behind a cover.

Replacing fuses

Remove the cover of the fuse box in the direction of the arrow.
› Remove the plastic clip (Fuse Puller) from the holder in the fuse box cover in the dash panel.
› Place the clip on the respective fuse and pull this fuse out.
› Insert a new fuse.

Fuses in the dash panel
Fuses in the dash panel

Assignment of the fuses in the dash panel


Skoda Rapid - Schematic representation of the fuse box for vehicles with lefthand steering
Schematic representation of the fuse box for vehicles with left hand steering


Schematic representation of the fuse box for vehicles with right hand steering
Schematic representation of the fuse box for vehicles with right hand steering

Fuse Table


No.  Power consumer
1 S-contact
2 START - STOP
3 Instrument cluster, headlight range adjustment, telephone, oil level sensor, diagnostic port
4 Control unit for ABS/ESC, steering angle sensor strip with switches
5 Petrol engine: Speed regulating system
6 Reversing light (manual gearbox)
7 Ignition, engine control unit, automatic gearbox
8 Brake pedal switch, clutch switch, engine cooling fan
9 Operating controls for the heating, electronic control unit for air conditioning system, park distance control, window lift, engine cooling fan, heated washer nozzles
10 DC-DC converter
11 Mirror adjustment
12 Control unit for trailer detection
13 Electronic control unit for automatic gearbox, selector lever of the automatic gearbox
14 Headlight beam control
15 Not assigned
16 Power steering, speed sensor, engine control unit, control unit for fuel pump
17 Daytime running lights/radio for vehicles with START-STOP
18 Mirror heater
19 Ignition lock input
20 Engine control unit, electronic control unit for fuel pump, fuel pump
21 Reversing lamp (automatic gearbox), fog lights with the function CORNER
22 Operating controls for the heating, electronic control unit for air conditioning system, telephone, instrument cluster, steering angle sender, multi-function steering wheel, ignition key removal lock, diagnostic port
23 Interior lighting, storage compartment and luggage compartment, side lights
24 Central control unit
25 Not assigned
26 Rear window wiper
27 Not assigned
28 Petrol engine: Purge valve, PTC heater
29 Injection, coolant pump
30 Fuel pump, ignition system, cruise control
31 Lambda probe
32 High pressure fuel pump, pressure valve
33 Engine control unit
34 Engine control unit, vacuum pump
35 Switch illumination, number plate light, parking light
36 Main beam
37 Rear fog light, DC-DC converter
38 Fog lights
39 Air blower for heating
40 Not assigned
41 Heated front seats
42 Rear window heater
43 Horn
44 Windscreen wipers
45 Boot lid lock, central locking system
46 Alarm
47 Cigarette lighter, power socket in the luggage compartment
48 ABS
49 Turn signal lights, brake lights
50 DC-DC converter, radio
51 Electric windows (driver's window and rear left window)
52 Electric windows (front passenger's window and rear right)
53 Windscreen washer
54 START-STOP instrument cluster, steering wheel module, multi-function steering wheel
55 Control unit for automatic gearbox
56 Headlight cleaning system
57 Low beam on the left
58 Low beam on the right

  Engine Compartment Fuse Block



Replacing fuses


› Press the lock buttons on the cover together simultaneously in the direction of the arrow 1
› Remove the cover in the direction of the arrow 2 .
› Replace the appropriate fuse.
› Place the cover on top of the fuse box.
› Push in the interlocks on the cover and lock.
The cover must engage firmly.

Vehicle battery: Cover for the fuse box (variant 1)
Vehicle battery: Cover for the fuse box (variant 1)

Vehicle battery: Cover for the fuse box (variant 2)
Vehicle battery: Cover for the fuse box (variant 2)

Fuse assignment in the engine compartment


Skoda Rapid - Schematic representation of fuse box in engine compartment: Version 1/version 2
Schematic representation of fuse box in engine compartment: Version 1/ Version 2

No. Power consumer
1 Generator
2 Not assigned (version 1), auxiliary electric heater (version 2)
3 Interior (version 1) Power supply for fuse block (version 2)
4 Auxiliary electric heating (version 1) Interior (version 2)
5 Interior
6 Engine cooling fan, control unit for preheating unit
7 Electrohydraulic power steering
8 ABS
9 Radiator fan
10 Automatic gearbox
11 ABS
12 Central control unit
13 Electrical auxiliary heating system

Note - Fuses 1-7 are replaced by a specialist garage.
